Vacuum Circuit Breaker
KamPa Vacuum Circuit Breaker for medium-voltage systems enables stable power distribution and fault interruption, supporting manufacture-based procurement with defined electrical ratings and endurance.
Can't find what you're looking for?
For decades, KamPa has been dedicated to helping numerous well-known enterprises and institutions customize reliable equipment. With strong production capabilities and professional expertise, we ensure that our equipment is fully compliant and meets your requirements.
Products Advantage
Direct Manufacturer
OEM/ODM Customization
Flexible MOQ Options
Dedicated Account Support
Kampa Electric Vacuum Circuit Breaker Manufacturer
- Rated voltage up to 40.5 kV for medium-voltage distribution systems
- Rated current options of 1250 A and 1600 A for varied load requirements
- Short-circuit breaking current rated at 21 kA and 31.5 kA
- Mechanical life rated for 10,000 operating cycles
- AC/DC 220 V mechanism control voltage for common control systems
What is a Vacuum Circuit Breaker?
A Vacuum Circuit Breaker is a switching device that uses a vacuum interrupter to extinguish arcs during current interruption in medium-voltage power systems.
How does a Vacuum Circuit Breaker interrupt fault current?
Vacuum Circuit Breaker operation separates contacts inside a vacuum chamber, where the absence of ionized gas enables rapid arc extinction and current interruption.
Which applications use a Vacuum Circuit Breaker?
Vacuum Circuit Breaker units are used in substations, industrial plants, and distribution networks operating up to 40.5 kV.
How is the rated short-circuit capacity selected?
Rated short-circuit capacity is chosen based on system fault level calculations, matching the 21 kA or 31.5 kA breaking ratings to network requirements.
What control power is required for a Vacuum Circuit Breaker?
Vacuum Circuit Breaker mechanisms operate with AC/DC 220 V control voltage, compatible with standard protection and control systems.
